Optical Fiber Distribution mini-Terminal & Splitter (MST) – OptiTap® compatible

The LiteLinx mini-MST is a compact, pre-terminated fiber distribution terminal built for fast deployment and long-term reliability in FTTx and FTTH networks. Each unit includes a factory-integrated 1:n PLC splitter (choose from 1x4, 1x6, 1x8, or 1x12) for efficient signal distribution and tool-free installation via hardened SC/APC ports compatible with OptiTap® connectors.

Rugged, Pre-Terminated Fiber Access Solution for FTTx Networks

Its IP68-rated enclosure withstands extreme temperatures, water, and dust, making it suitable for aerial, pedestal, pole-mount, or handhole installations. Designed for plug-and-play simplicity, the mini-MST eliminates the need for fusion splicing in the field—dramatically reducing time and cost per install.

Whether you’re deploying broadband in dense urban environments or extending connectivity to rural communities, the LiteLinx mini-MST makes fiber distribution fast, durable, and effortless.



Key Features:

• Available with 1x4, 1x6, 1x8, or 1x12 PLC splitters
• Plug-and-play OptiTap®-compatible SC/APC ports
• IP68-rated UV-stabilized PC+ABS plastic housing
• Compact and lightweight: 260 × 195 × 75 mm; < 1.5 kg
• Supports wall, pole, strand, pedestal, or handhole mountin
• Suitable for FTTH, FTTx, rural broadband, and rapid installs



Specifications:

Splitter Type	1x4, 1x6, 1x8, 1x12 PLC (Planar Lightwave Circuit)
Fiber Type	G.657.A1 Singlemode Bend-Insensitive
Output Connectors	SC/APC (OptiTap® Compatible)
Tail Length	5 m to 2000 m (Customizable)
Enclosure Rating	IP68
Operating Temperature	–40°C to +85°C
Material	UV-resistant PC+ABS plastic
Dimensions	260 mm × 195 mm × 75 mm (approx.)
Weight	< 1.5 kg (without drop cables)
Mounting Options	Wall, Pole, Strand, Pedestal, Handhole

Application Scenarios

This Squid-style distribution terminal is perfect for:

• FTTH and FTTx deployments
• Rural broadband rollouts
• MDUs and residential complexes
• Rapid greenfield and brownfield fiber builds
• Temporary or mobile fiber access points

Whether you’re deploying fiber to suburban neighborhoods, utility poles, or rural communities, this OptiTap®-ready solution saves time in the field and delivers long-term durability in the toughest conditions.
